CF2.5 PLUS

TORQUE 25 - 35 kNm
ENGINE POWER 49,9 kW
MAX DEPTH 20 m
MAX DIAMETER 1000 mm
TOTAL WEIGHT

8 - 9 t *

* with counterslide device



Hydraulic piling rig CF2.5 PLUS

Equipped with a special mast divided into two telescopic sections with counter-slide device to lower the mast group down the ground and reach the minimum working position of 2800mm. The CF2.5 PLUS is equipped with a standard locking kelly bar for a depth of 15m, working under 3000mm. The mast can be provided with a third element that allows the use of a 20m locking kelly bar, working at a maximum height of 6300mm. With a minimum undercarriage width of 1920mm, the CF2.5 PLUS can move in very narrow places and limited areas. The undercarriage is equipped with rubber tracks to work easily on any surface.



CF2.5 PLUS

TORQUE 25 - 35 kNm
ENGINE POWER 49,9 kW
MAX DEPTH 20 m
MAX DIAMETER 1000 mm
TOTAL WEIGHT

8 - 9 t *

* with counterslide device



Hydraulic piling rig CF2.5 PLUS

Equipped with a special mast divided into two telescopic sections with counter-slide device to lower the mast group down the ground and reach the minimum working position of 2800mm. The CF2.5 PLUS is equipped with a standard locking kelly bar for a depth of 15m, working under 3000mm. The mast can be provided with a third element that allows the use of a 20m locking kelly bar, working at a maximum height of 6300mm. With a minimum undercarriage width of 1920mm, the CF2.5 PLUS can move in very narrow places and limited areas. The undercarriage is equipped with rubber tracks to work easily on any surface.
